HIGH VOLTAGE SPARK TESTERS
|
|
ST-R REMOTE PROBE SPARK TESTER |
|
The ST-R spark tester is a remote probe type of electro-mechanical spark generator producing an output voltage that is adjustable between 10kV and 55kV. The tester is powered by either 110Vac or 230Vac
mains supply. The spark generator is housed in a thermoplastic housing and
is connected to the remote probe by 2 metres of cable. Spark
generation is activated by pressing the switch on the remote probe All the accessories for the E1D unit will fit the ST-R tester |
|
E1/D SPARK TESTER |
|
The E1/D spark tester is a hand held electro-mechanical spark generator producing an output voltage that is adjustable between 10kV and 55kV. The tester is powered by either 110Vac or 230Vac mains supply. Suitable for intermittent use, the unit is housed in a moulded pistol shaped case enabling single handed operation. The high frequency coil is a plug-in type to allow easy replacement. A range of probes and electrodes is available to suit all applications. |
E1/D SPARK TESTER KIT |
|
The E1/D Kit contains a spark tester along with
the following:- 1 Spare HF coil 1 Gauze electrode 1 Copper brush electrode 1 Steel brush electrode 1 Flexible probe 1 Short pointed probe 2 200mm extension rods All in a fitted carrying case. |
_______________________________________________________ |
|
|
|
|
Item | Application | Part Number | |
HF Coil | Replacement part | E3 | |
Gauze electrode | Flat surfaces | E4 | |
Flexible probe | General use | E5 | |
Steel brush electrode | Irregular surfaces | E6 | |
Short pointed probe | Small areas | E7 | |
Copper brush electrode | Large irregular surfaces | E8 | |
200mm extension rod | Inaccessible surfaces | E9 | |
450mm extension rod | Inaccessible surfaces | E10 | |
_______________________________________________________ |
